| Nominal Input Level |
-20 dBu |
| Input Impedance |
-20 dBu |
| Nominal Output Level |
OUTPUT jack: -20 dBu
LINE OUT jack: -20 dBu |
| Output Impedance |
1 k ohm |
| Recommended Load Impedance |
10 k ohms or greater |
| Bypass |
Buffered Bypass Control |
| Controls |
Pedal switch | THRESHOLD knob | RATIO knob | RELEASE knob | LEVEL knob |
| Indicators |
CHECK indicator (Serves also as battery check indicator)
GAIN REDUCTION indicator |
| Connectors |
INPUT jack OUTPUT jack DC IN jack |
| Power Supply |
Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately)
Working Voltage – 18 V
Current Draw – 90 mA
Expected battery life under continuous use
Alkaline: Approx. 3 hours
(These figures will vary depending on the actual conditions of use.) |
| Size and Weight |
Width: 73 mm | 2-7/8 inches
Depth: 129 mm | 5-1/8 inches
Height: 59 mm | 2-3/8 inches
Weight(including battery): 450 g | 1 lb |
