| Nominal Input Level |
-20 dBu |
| Input Impedance |
1 M ohm |
| Nominal Output Level |
-20 dBu |
| Output Impedance |
1 k ohm |
| Recommended Load Impedance |
10 k ohms or greater |
| Bypass |
Buffered Bypass |
| Controls |
MODE knob | RATE knob | DEPTH knob | RES (Resonance)/MANUAL knob | Pedal switch |
| Indicators |
CHECK indicator (Serves also as battery check indicator) |
| Connectors |
GUITAR IN jack: 1/4-inch phone type
BASS IN jack: 1/4-inch phone type
OUTPUT A (MONO) jack: 1/4-inch phone type
OUTPUT B jack: 1/4-inch phone type DC IN jack |
| Power Supply |
Carbon-zinc battery (9 V, 6F22) or Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)
Current Draw – 40 mA
Expected battery life under continuous use:
Carbon: Approx. 3 hours
Alkaline: Approx. 10 hours
*These figures will vary depending on the actual conditions of use. |
| Size and Weight |
Width: 73 mm 2-7/8 inches
Depth: 129 mm 5-1/8 inches
Height: 59 mm 2-3/8 inches
Weight (including battery): 435 g | 1 lb |
