| Sampling Frequency |
44.1 kHz |
| Conversion |
24 bits + AF method
AF method (Adaptive Focus method) is a proprietary method from Roland
and BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.
DA Conversion – 24 bits |
| Patches |
99 (User) + 99 (Preset) |
| Phase Loop |
32 sec. |
| Nominal Input Level |
INPUT: -10 dBu,
AUX IN: -20 dBu |
| Maximum Input Level |
INPUT: +7 dBu,
AUX IN: 0 dBu |
| Input Impedance |
INPUT: 1 M ohm
AUX IN: 27 k ohms |
| Nominal Output Level |
OUTPUT (L/MONO, R): -10 dBu
PHONES: -10 dBu |
| Output Impedance |
UTPUT (L/MONO, R): 1 k ohm
PHONES: 44 ohms |
| Recommended Load Impedance |
OUTPUT (L/MONO, R): 10 k ohms or greater
PHONES: 44 ohms or greater |
| Controls |
DOWN switch | UP switch | CTL1 switch | EASY SELECT button | EASY EDIT button | FX1/LIMITER button |
OD/DS button | PREAMP button | FX2/MOD button | DELAY button | REVERB button | MEMORY EDIT button |
EXIT button | ENTER button | MENU button | 1 knob | 2 knob | 3 knob | Expression pedal |
| Display |
Graphic LCD (132 x 32 dots, backlit LCD) |
| Connectors |
INPUT jack, OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
CTL2, 3/EXP2 jack: 1/4-inch TRS phone type
AUX IN jack: Stereo miniature phone type
USB COMPUTER port: USB type B DC IN jack |
| Power Supply |
Alkaline battery (AA, LR6) x 4
or
AC adaptor (sold separately)
Expected battery life under continuous use
Alkaline: Approx. 7 hours
These figures will vary depending on the actual conditions of use. |
| Current Draw |
200 mA |
| Size and Weight |
Width: 305 mm | 12-1/16 inches
Depth: 152 mm | 6 inches
Height: 56 mm | 2-1/4 inches
Maximum height: 74 mm | 2-15/16 inches
Weight (including battery): 1.3 kg | 2 lbs | 14 oz |
